Descripción
The Kromschroder DG 150VC4-6W pressure switch, art: 84448933 is used to assemble automatic flow control systems when operating industrial installations with a medium pressure of up to 600 mbar. It monitors the differential, overpressure and vacuum pressure of flammable gases, air.
Main parameters and features:
- monitored media: air, gas, including methane produced biologically (H2S content < 0.1%);
- high switching accuracy;
- wide measurement range, setting within 40-150 mbar;
- for industrial-type installations with a gas/air pressure not exceeding 0.6 bar;
- compact size, easy installation in the system;
- reliable design, materials of the body and structural elements: PBT plastic reinforced with fiberglass, with low gas permeability, AlSi 12;
- working membrane, reacting to changes in pressure, made of NBR rubber;
- electrical connection: DIN connector;
- smooth adjustment of the switching point with a handwheel;
- dust and moisture protection level of the housing class IP 54;
- wide range of operating temperatures: -15...+80 °C;
- mounting horizontally, vertically (preferred).
Gas and air pressure switches are installed in industrial ventilation equipment, air conditioning systems, gas-consuming units. They are tested and certified according to EG-Baumuster.
Características
Número de pieza del fabricante: 84448933Maximum working pressure: 600 mbarAdjustment range: from 40 to 150 mbarOperating ambient temperature: from -15 to 80 °CDegree of protection: IP54For controlling: differential pressure, excess pressure, vacuum pressureWorking environment: flammable gases, air
La información sobre las características técnicas, la apariencia y el color del producto es solo de referencia y se basa en la información más reciente disponible en el momento de la publicación
