Kromschroder BCU 465W3P1C2D0000K1E1-/LM400WF3O0E1- burner automatic
Kromschroder88682573
Precio: DOP 311000
Descripción
The Kromschroder BCU 465W3P1C2D0000K1E1-/LM400WF3O0E1-/… burner control unit, art: 88682573 combines components of an automatic burner control unit, ignition transformer, manual/automatic mode, indication of operating states and faults, as well as a user interface in a compact housing. It is used in industrial forced-draft gas burners. Ensures safe and efficient operation of the boiler installation.
Features and functions:
- for systems with progressive power regulation;
- continuous, intermittent operating mode;
- power supply from 220-240 V, 50-60 Hz;
- flame control using UV radiation, ionization;
- built-in ignition transformer;
- easy integration into the system using BCSoft software for programming and diagnostics on a computer;
- fast response to flame signal loss (< 1 sec.);
- additional valve check system;
- permissible operating temperatures: -20...+60 °C;
- air valve control, advanced air control;
- use in burners of unlimited power;
- automatic/manual control mode;
- metal ergonomic housing with display;
- indication of current status, settings and flame signal strength;
- remote control capability;
- fast and reliable electrical connection;
- socketless design.
Kromschroder BCU 465 burner control units can be supplied to operate at high temperatures and in low NOx mode (optional).
Características
Número de pieza del fabricante: 88682573Burning method: turbochargedOperating mode: continuous operation, intermittent, manualPresence of a plinth: noFuel type: gaseousBurner type: progressiveVoltage: 220 V
La información sobre las características técnicas, la apariencia y el color del producto es solo de referencia y se basa en la información más reciente disponible en el momento de la publicación
