Pressure switches of type KR/KRI are designed for regulation, current monitoring and emergency signaling in industry. They are installed in systems with liquid and gaseous media.
Features and characteristics:
Pressure range: -0.2...28 bar;
Very short response time;
Suitable for switching AC and DC loads;
For gaseous media and air;
IP44 enclosure protection class when mounted with top cover and rear board;
Special housing art.: 060-033066 / 060-062866, increasing the enclosure protection class to IP55;
Compact dimensions do not require much space;
Easy installation;
Resistance to shock and vibration.
Características
Maximum working pressure: 18,000 mbarShift differential: 400 - 1,500 mbarDegree of protection: IP30, IP30Connection type: G 1/4"Type of connection: cable entry PG13.5Pressure measurement range: from 1 to 18 barOperating ambient temperature: from -40 to 60 °CAdjustment range: from -200 to 8,000 mbarOperating principle: differentialFor controlling: differential pressureWorking environment: liquids, air, carbon dioxide and other inert gases
